Frame Capacity

 Max. 0 ~ 200Kgf (2KN)

Load Range

 4 Steps

Load Resolution

 1/100,000

Stroke Resolution

 0.001mm

Testing Size

 170 × 800 (W Х H mm)

Column Type

 One column

Controller

 Touch Type LCD Digital Indicator

Ball Screw

 THK Ball Screw (Japan)

Testing Speed

 0.01-500mm/min

Motor & Driving System

 MITSUBISHI Servo Motor &Servo Driver

Safety

 Limit,Load & Stroke Limit Emergency Stop

Power Supply

 AC220V, 50/60Hz

Weight

 50kg

Dimension

 450×400×1200 (W Х D Х H) mm

Testing Grips

 Option

Elongation_Meter

 Encoder Type or Strain Gague Type

Software OS

 Window exclusive U.T.M
